CK-UV Series of UV Laser Machine
CK-UV series of UV laser machine
Equipment Description
CK-UV series of UV laser machine adopt imported high quality UV laser source, with ultra small focus spot ,and its heat effect is very weak, which are fit to mark those materials with large thermal radiation reaction. It is mainly used to mark/engrave/cut those special materials and ultra-fine processing. It is widely used in ultra-fine laser processing of high-end market.
1. High good beam quality, very small light spot , which can achieve ultra precise
marking,and the minimum character can up to 0.2mm
2. The output wavelength is 355nm,which can reduce the heat effect when processing, there is no deformation and burn phenomenon in workpieces.Equipment Description
CK-UV series of UV laser machine adopt imported high quality UV laser source, with ultra small focus spot ,and its heat effect is very weak, which are fit to mark those materials with large thermal radiation reaction. It is mainly used to mark/engrave/cut those special materials and ultra-fine processing. It is widely used in ultra-fine laser processing of high-end market.
| Mode | CK-UV |
| Laser power | 8W(optional) |
| Laser wavelength | 355nm |
| Gross power | 1200W |
| Size | 1600mm×1176mm×1905.94mm |
| Environment request | temperature15-30℃/humility20-80% |
1. High good beam quality, very small light spot , which can achieve ultra precise
marking,and the minimum character can up to 0.2mm
3. Adopting the top advanced light wave laser source from USA, the performance is excellent
4.The design of machine’s exterior adopts up and down slide door to make the marking process closely
and the observation window was made by high quality
specified filter organic glass, which can greatly improve the protective performance.
5.With optional auto focus, auto lifting and rotary’s functions.
Technical parameter :
| Marking range | 50mm×50mm/100mm×100mm（optional） | |
| Repeat frequency | Single pulse up to 300KHz | |
| Minimum line width | 0.01mm | |
| Marking speed | ≤7000mm/s | |
| Cooling system | Air cooling/water | |
| Supply voltage | AC220V/50-60Hz | |
